Telescopic Mast VM6-5-ME
Product Feature:
1. Payload:50/100KGS
2. Height: 5m
3. Weight:100/110KGS per set
4. Wind Rating Speed: 120km
Share this :
Tech Specs
Gallery
MAST PARAMETER
| Extended Height: | 5000mm/37’1” |
| Retracted Height: | 1300mm/8’12” |
| Number of sections: | 6&1.0m per Section |
| Wind Rating Speed: | 120kph |
SQUARE TUBE DIMENSION
| Height of each section: | 1000mm |
| Top tube size: | 60 Squareness |
| Second tube size: | 80 Squareness |
| Third tube size: | 100 Squareness |
| Fourth tube size: | 120 Squareness |
| Fifth tube size: | 140 Squareness |
| Base tube size: | 160 Squareness |
| Type: | Multi-Section Retractable Mast |
| Anti-corrosion
Treatment: |
Galvanization& Powder Coat |
PARTS FOR OPTION
| Hand Winch: | 1800Lbs Self-locking |
| Electric Winch: | 4500Lbs
DC12/24V |
| Hydraulic Cylinder: | 2.2KW DC12/24V AC110-240V |
| Cable: | 5m Spiral |
| Tensioning Ropes: | 6m(φ6mm)*3 |
